Diesel Horizontal Slurry Pump
HRZL-C/ZJW diesel horizontal slurry pump adopts high-quality hydraulic model, high efficiency and good performance. It adopts double pump casing structure, which is easy to install and maintain.
This pump is suitable for industrial fields such as metallurgy, mining, coal, electricity, building materials, etc. It can transport medium containing particles, has the characteristics of corrosion resistance and can handle high-concentration slurry. According to the working conditions, it can be driven by either electric motor or diesel engine.
High concentration, volume concentration can reach 60%, weight concentration can reach 70%.
Diameter size: outlet size ranges from "1 to 22".
Advanced hydraulic design, soft start and variable frequency speed regulation, energy saving and high efficiency.
Strong passing capacity: The maximum particle size of the gravel pump is 380mm.
Corrosion and wear resistant, available in a wide range of materials, suitable for pH 1.0–14.
Our company has passed ISO certification, and all pumps have passed CE certification, which meets international standards.
| Size | Flow (m³/h) | Head (m) | Power (kw) | Speed range (r/min) |
|---|---|---|---|---|
| 4inch | 64-365m³/h | 16-100.2m | 45-160KW | 980-1480r/min |
| 6inch | 142-600m³/h | 21-93.8m | 75-220KW | 730-1480r/min |
| 8inch | 296-976m³/h | 28.8-133.7m | 185-560KW | 730-980r/min |
| 10inch | 405-1796m³/h | 32-128.7m | 280-800KW | 590-980r/min |
| 12inch | 588-2333m³/h | 21.5-79.9m | 250-450KW | 490-980r/min |
We provide OEM and ODM services, and can customize specifications, colors and sizes to find your best solution.
Customer Service
Customization of specifications, colors and OEM products.
We provide DDP (Delivered Duty Paid) service. Most equipment is in stock for fast delivery.
Our testing facility can handle large-scale tasks. Pump models for wet and dry tank operation up to 400 HP.
